Technical details

Operation Easy-Lift-Balance system
Fabric Premium acrylic awning fabric in more than 120 colours (light-fast and weather-resistant). Also optionally available with water-permeable or fireproof fabrics.
Frame White RAL 9016, anthracite grey RAL 7016 or anodised silver, other RAL colours at extra charge.
Mast Aluminium mast with 50 mm diameter and 3 mm wall thickness
Struts Double-Layer power struts 30 x 15 x 2 mm with strut reinforcement

The benefits for you

  • Easy-Lift-Balance ensures easy opening in just a few seconds
  • Closes over tables and patio furniture thanks to sophisticated telescopic system
  • High wind stability due to double strut direction



Shapes
Max. size 5 x 5 m 4 x 5 m Ø 5 m
Max. shading 25 m2 20 m2 20 m2



Shapes Size Height open Height closed Headroom Closing height Handle height open Handle height closed Weight*
300 x 300 cm 282 cm 369 cm 225 cm 149 cm 175 cm 89 cm 38 kg
350 x 350 cm 291 cm 391 cm 225 cm 134 cm 174 cm 80 cm 42 kg
400 x 400 cm 300 cm 417 cm 225 cm 123 cm 173 cm 75 cm 48 kg
450 x 450 cm 309 cm 440 cm 225 cm 110 cm 177 cm 60 cm 53 kg
500 x 500 cm 317 cm 461 cm 225 cm 94 cm 180 cm 60 cm 60 kg
200 x 350 cm 279 cm 356 cm 225 cm 146 cm 167 cm 127 cm 35 kg
200 x 400 cm 285 cm 368 cm 225 cm 136 cm 173 cm 139 cm 38 kg
250 x 300 cm 278 cm 350 cm 225 cm 146 cm 181 cm 127 cm 35 kg
250 x 350 cm 283 cm 375 cm 225 cm 152 cm 171 cm 102 cm 38 kg
250 x 400 cm 288 cm 384 cm 225 cm 139 cm 176 cm 111 cm 40 kg
250 x 450 cm 293 cm 398 cm 225 cm 130 cm 176 cm 114 cm 43 kg
300 x 400 cm 292 cm 398 cm 225 cm 138 cm 175 cm 92 cm 43 kg
300 x 450 cm 297 cm 414 cm 225 cm 133 cm 175 cm 81 cm 45 kg
300 x 500 cm 302 cm 425 cm 225 cm 122 cm 175 cm 90 cm 48 kg
350 x 400 cm 295 cm 409 cm 225 cm 134 cm 173 cm 73 cm 45 kg
350 x 450 cm 300 cm 423 cm 225 cm 128 cm 178 cm 74 cm 48 kg
350 x 500 cm 305 cm 439 cm 225 cm 123 cm 178 cm 60 cm 50 kg
400 x 500 cm 309 cm 445 cm 225 cm 113 cm 177 cm 55 cm 53 kg
Ø 350 cm 272 cm 348 cm 225 cm 168 cm 175 cm 125 cm 46 kg
Ø 400 cm 278 cm 369 cm 225 cm 163 cm 171 cm 107 cm 50 kg
Ø 450 cm 285 cm 386 cm 225 cm 155 cm 178 cm 106 cm 54 kg
Ø 500 cm 291 cm 406 cm 225 cm 149 cm 174 cm 86 cm 58 kg

* Weight in kilos for a standard parasol without extras.

Acrylic awning fabric (standard)

The tried and tested acrylic awning fabric is manufactured from 100% spinning nozzle dyed brand acrylic fabric. That means that the colour pigments – unlike in classic yarn dyeing – are applied during the fibre production. This ensures reliable protection against damaging UV radiation and permanently guarantees brilliant colours / constant weather and light-fastness. Furthermore, the acrylic fabric is especially tear-resistant and also dirt and water-repellent thanks to its impregnation with a special protective agent. The reliable solution for long-term outdoor use.



  • Water-proof up to 300-370 mm water column, EN 20811
  • High colour and weather fastness (7-8) of 8
  • Water and dirt-repellent
  • 100% acrylic 285–300 g/m²
  • Commercial printing possible on canopy and valance

Go to fabric selection…

Acrylic awning fabric LUMERA

The innovative Lumera acrylic fabric is woven with the special CBA fibre (Clean Brilliant Acrylic). Along with all the benefits of the acrylic fabric, this provides even more bonuses. The acrylic multifilament fibre has a smoother and denser surface. This means that the colours turn out richer and more radiant and the fabric’s luminance is increased for a long time.



  • Water-proof up to 460 mm water column, EN 20811
  • High colour and weather fastness (7-8) of 8
  • Water and dirt-repellent
  • 100% acrylic 290 g/m²
  • Commercial printing possible on canopy and valance

Go to fabric selection…

Swela Sunvas Uni

This 100% polyester fabric has an innovative and effective dirt and water-repellent SNC impregnation. This makes the fabric air-permeable, weather-proof and resistant to rooting. The fabric also has a high elasticity without permanent stretching. It is therefore optimally suited for outdoor use.



  • Water-proof up to 350 mm water column, EN 20811
  • High light and weather fastness (7-8) of 8
  • Chlorine fastness (4-5) of 5
  • Polyester mesh with SNC impregnation
  • Surface weight approx. 310 g/m²
  • Water and dirt-repellent
  • Excellent sun protection (UPF 50+)

Frame colours for masts and struts

You can find over 200 RAL colours here.

Easy-Lift-Balance system

Supremo has a particularly innovative sliding mechanism: With the tap of a finger on the locking switch, the parasol automatically unfolds halfway using its own weight. All that's left to do is lightly push the handle upward and lock it. This system allows for quick and easy handling, even with large parasols.

Struts with double support

The double strut hub provides double support for the main struts, to which the fabric is attached. An interior aluminium profile provides additional strut support for large parasols. This makes the parasol especially robust and wind-stable.

Stainless steel handle with locking switch

Quality in all parts – the stainless steel handle of the Supremo is practical as well as especially stable! When opening and closing the parasol, its locking switch snaps into place automatically.

Sophisticated telescopic system

The advantage: the telescopic system extends the mast when closing! Tables and patio furniture can stay where they are.

Parasol bases

Here you will find a parasol base to suit every parasol. CARAVITA offers a wide range of models for all purposes in many different colours and shapes. Learn more…

Ground sleeves and pole fittings

Ground sleeves are parasol bases to be set in concrete. Depending on the quality of the ground, ground sleeves are available in different lengths. The upper part of the ground sleeve can be removed. The part remaining in the ground is then at ground level. Learn more…

The 2019 catalogue is available!

Experience the world of CARAVITA

Download now…

References

The Supremo is as versatile as you need it to be.

Burtons Grill, Mount Pleasant, South Carolina, USA
Supremo parasol 3.5 m x 3.5 m, frame RAL 8011 nut brown, fabric U406 chestnut, edge trimming E409 rust.
Learn more...
Kipfenberg outdoor swimming pool, Germany
Supremo parasol, 4 m x 4 m, fabric U405 red, frame RAL 7016.
Learn more...
Golf Club Starnberg, Germany
Supremo PLUS parasol 4.5 m x 4.5 m, fabric U101 white, frame anodised silver.
Learn more...
Supremo parasol, private installation, USA
Supremo parasol, 4 m x 4 m, fabric U608 blue and U101 white, “Loop” design, sewed-on valance, Rom 90kg parasol base and Supremo 3.5 m round, fabric U608 blue and U101 white, “Turnaround” design, flowing valance, wind roof, Florence 55 kg parasol base.
Learn more...
Supremo, private installation, Switzerland
Supremo 3×3 m, frame high gloss look, fabric acrylic waterpr. white U101, edge trimming white 00 without valance, with wind roof.
Learn more...
Murrhardt outdoor swimming pool, Germany
Supremo parasol Ø 5.5 m, different fabric colours, frame anodised silver
Learn more...

* 5 years according to our warranty conditions
